Cell Density Sensors

Dencytee Arc RS485

Hamilton's Dencytee Arc RS485 sensor is an in-line optical transmittance and reflectance sensor capable of accurately measuring the total cell density and turbidity of the whole bioprocess from inoculation to harvesting.

Receive More Information

  • Dencytee RS485 Cell Density Sensor

Commonly Grouped Accessories

Dencytee Arc RS485 Details

Hamilton’s Dencytee Arc RS485 is an in-line optical sensor that measures total cell density and turbidity via transmittance and reflectance. Its robust design adapts to changes in ambient light and temperature, ensuring you never miss an important event during your bioprocess.  Additionally, it features easy air verification with our Maintenance Tool Kit.

All particles and molecules that scatter light at 860 nm will be detected, including living and dead cells as well as cell debris. This sensor can also be utilized as a turbidity sensor for monitoring crystallization, filtration and dissolving processes.

Hamilton’s Arc technology provides a robust connection directly to the Process Control System without the need for an additional external transmitter.

Common applications Cell Biology, Cell Culture, Power, Energy, & Environment, Water and Wastewater, Chemical Processes

Enhance process understanding with real-time data from continuous measurement.

Never miss an important event during your bioprocess.

Robust design adapts to changes in ambient light and temperature.

Easy Transmitter-less

  • Hamilton Arc technology enables seamless integration to a control system, PLC, or DCS without a bulky transmitter.
  • Leverage the Arc platform to perform maintenance and configuration with ArcAir™ software.

Correlation to Off-line Measurements

  • With Dencytee Arc, a built-in correlation model provides a robust link between the in-line optical density signal and commonly used off-line measurements of biomass.
  • Enables real-time, in-situ data of off-line biomass concentrations.
 Pause Mute
/
Enter Fullscreen
Use case

How It's Used

Never miss an important event of your bioprocess. From increasing yield to shortening process time, the real power of Hamilton's optical density sensors is in your hands.

  • We value the versatility and ease of integration of the Dencytee Arc system.

    In our QbD-centered PAT ecosystem, which requires frequent adaptation to different bioprocess modes and R&D setups, we especially value the versatility and ease of integration of the Dencytee Arc system.

    Prof. Dr. Lukas Neutsch
    Head Bioprocess Technology, Zurich University of Applied Sciences

  • Hamilton sensors enhance safety, efficiency, and reliability in chemical processes.

    Hamilton sensors and retractable fittings are not only essential for monitoring and controlling our chemical processes, but also make preventive maintenance and fault diagnosis much easier. The robustness and durability of the products mean fewer emergency call-outs and greater overall plant effectiveness. Overall, the sensors make a significant contribution to the safety, efficiency and reliability of our operating processes and help us to meet and exceed our high standards.

    Dimitri Brumm
    EMR Operating Engineer - Cassella Chemiepark

Dencytee Arc RS485 Specifications

Sensor Family Dencytee Arc
Parameter Total Cell Density
Electrical Connector VP8
Sensor Output Arc: Modbus
Wavelength 860 nm
Measuring Range e.g. 0-200g/l cell dry weight yeast
0-4 AU
0-30'000 NTU
Accuracy at 25 °C Resolution: 0.05 g/l (0-10 g/l); 0.5 % (> 10 g/l) cell dry weight yeast
Reproducibility: ± 1 %
Linearity: < ± 1% of respective measuring range (specific to application with off-line correlation)
Temperature Sensor NTC 22 kOhm
Configurable Values TCD: PCV, AU, arb. Unit, NTU, g/l, CFU, e6 cells/ml, OD
Temperature: K, °C, °F
Diameter 12 mm
Process Connection PG13,5
Wetted Parts Stainless Steel 1.4435
Sapphire glass
EPDM (Ethylene propylene elastomer)
See compliance details in Material Specification document
Surface Quality of Steel Ra < 0.4 µm (N5)
Digital Interface RS485 Modbus (max. 32 addresses)
Baud Rate 4800, 9600, 19200, 38400, 57600,115200 Bd
Operating Voltage +10 to +27 VDC
Optical Path Length 5 mm
Serial Number Yes
Certificate Yes, in water and at 10'000 NTU Standard
ATEX Approval No
IECEx Approval No
Autoclavable Yes (140°C, 30-minute sterilization duration)
CIP Yes (3% NaOH, 90°C, 30-minute cleaning duration)
Steam Sterilizable Yes (140°C, 30-minute sterilization duration)
Storage Conditions -20 °C to 45 °C
Operating Temperature Range 0 to 140 °C; the sensor provides no TCD reading above 80 °C.
Pressure Range bar g 0 to 12 bar
Protection Rating IP 68

Compatibility with Hamilton Devices.

Explore the limitless possibilities of Hamilton products.

Dencytee Arc RS485 Resources

Browse app notes, user guides, specification documents, and more in our Knowledge Center.

Material Specification

Dencytee Sensors and Units

Technical Drawing

Dencytee RS485

Technical Manual

Dencytee Arc Sensors

Browse app notes, user guides, specification documents, and more in our Knowledge Center.

Material Specification

Dencytee Sensors and Units

Technical Drawing

Dencytee RS485

Technical Manual

Dencytee Arc Sensors

Browse app notes, user guides, specification documents, and more in our Knowledge Center.

Wiring for Dencytee Arc Total Cell Density Sensors

Dencytee Arc total biomass sensors come standard with Modbus RTU (RS485) digital protocol. This article helps you wire a total cell density sensor.

Cost-Efficient Cultivated Meat Production Through Deeper Process Insights

Dencytee Arc Total Cell Density Measurement Principle

Optical density (OD, sometimes called turbidity) is commonly used to estimate the total biomass or concentration of cells within a suspension. Cell concentrations are important to monitor in fermentation processes to detect and correct for process deviations.

Browse app notes, user guides, specification documents, and more in our Knowledge Center.

What is special about the Dencytee Arc?

The Dencytee Arc uses two different optical methods: a transmitted light measurement and a reflection measurement. It is effectively a "transflectance" probe.

How do I calibrate my Arc sensor?

ArcAir Basic and Advanced software have built in calibration and report tools for Arc sensors. Connect the Arc sensor to ArcAir and utilize the step by step calibration instructions. Click to learn more about connecting Arc sensors to ArcAir software.

Strange values for the cell density appear for cell density (column E of the Excel spreadsheet). What does this mean?

Since negative values cannot be displayed, "0.00" is displayed if the cell density value is below zero. If the displayed value is -999.00, there is no communication with the probe.
