StatoFlex
Safety
Secure Cage
Protection
Sanitarity
Orbital Cleaning
Flushing
Versatility
Steel & Plastic
Materials
The StatoFlex Immersion Fittings feature integrated orbital sensor cleaning systems, ensuring thorough mechanical cleaning directly in the sensor range for effective maintenance. Available in stainless steel and plastic options to suit diverse process needs
Effective Maintenance through Orbital Cleaning
The StatoFlex immersion fittings are designed for processes requiring DN50 or ANSI 2" connections and incorporate an integrated orbital sensor cleaning system. This ensures a highly effective mechanical cleaning within the sensor range, minimizing maintenance needs.
Versatile Material and Length Options
To meet diverse application requirements, StatoFlex fittings are available in both robust stainless steel and lightweight plastic. Various lengths can be selected to suit different tank or open channel depths. The plastic model also offers an optional suspension holder for added versatility.
Integrated orbital flushing ensures thorough mechanical cleaning of the sensor, leading to reliable measurements and reduced manual intervention.
Designed for standard DN50 or ANSI 2" connections and available in stainless steel and plastic, fitting various process environments.
Offered in various immersion lengths, the StatoFlex immersion fitting can be tailored to different tank and channel depths, ensuring optimal sensor placement.
StatoFlex Specifications
StatoFlex Specifications
Print- Pressure Range (bar g)
- Steel: 0 to 10 bar
Plastic: 0 to 6 bar
- For Sensors with
- 12 mm; PG13,5; 120 mm; pH glass and ISFET
- Operating Temperature Range
- Steel: -10 to 140 °C
Plastic: -10 to 90 °C
- Immersion length
- 0.5 to 2.5 meters
- Material
- Steel: Stainless Steel 1.4404
Plastic: PP or PVDF
