OxyFerm FDA Arc 425
The OxyFerm FDA Arc 425 is an electrochemical oxygen sensor suited for applications with high demands for hygiene, e.g. in pharmaceutical industry, in biotechnology and in food & beverage production. It is available with 12 mm or 25 mm (XL) shaft diameter. The sensor is equipped with an FDA-approved membrane for use in hygienic processes. It withstands steam sterilization, autoclavation and CIP cleanings.
Found in these product categories:
Part/REF # 243104-
(In Stock)(In Stock)Stock status is updated daily. For real-time status, please contact us.
Specifications
Sensor Family |
Sensor Family
OxyFerm FDA
|
---|---|
Parameter |
Parameter
DO (Electrochemical)
|
Sensor Output |
Sensor Output
Arc: Modbus, 4 to 20 mA
|
a-length |
a-length
425 mm
|
Electrical Connector |
Electrical Connector
VP8
|
Measurement Principle |
Measurement Principle
Electrochemical reduction of oxygen
|
Measuring Range |
Measuring Range
10 ppb to 40 ppm (DO) or 0.2 to 1000 mbar (pO₂)
|
Additional specifications
Accuracy at 25 °C |
Accuracy at 25 °C
± 2 %
|
---|---|
Drift at Room Temperature |
Drift at Room Temperature
< 1 % per week
|
Sensor Cap |
Sensor Cap
Delivered with Optiflow FDA
|
Electrolyte |
Electrolyte
Oxylyte
|
Oxygen Consumption |
Oxygen Consumption
Ca. 20 ng/h in air at 25 °C
|
Temperature Sensor |
Temperature Sensor
NTC 22 kOhm
|
Configurable Values |
Configurable Values
DO: mbar; %-sat; %-vol; µg/l; mg/l; ppb/ppm (gas); ppb/ppm (dissolved oxygen); Temperature: °C, °F, K
|
Diameter |
Diameter
12 mm
|
Process Connection |
Process Connection
PG13,5
|
Surface Quality of Steel |
Surface Quality of Steel
Ra < 0.4 µm (N5)
|
Electrode system |
Electrode system
Silver platinum combination
|
Analog Interface 1 |
Analog Interface 1
4 to 20 mA for DO, programmable
|
Analog Interface 2 |
Analog Interface 2
4 to 20 mA for Temp., programmable
|
Analog Interface 1 and 2 |
Analog Interface 1 and 2
Galvanically not isolated; pulse width modulation 3.5 kHz
|
Baud Rate |
Baud Rate
4800, 9600, 19200, 38400, 57600,115200 Bd
|
Polarization Voltage and Time |
Polarization Voltage and Time
-670 ± 50 mV, ≥ 2 hours
|
Operating Voltage |
Operating Voltage
7 to 30 VDC max. 150 mW
|
Serial Number |
Serial Number
Yes
|
Response Time |
Response Time
t98% < 60 s at 25 °C
|
Certificate |
Certificate
Yes, with parameter settings and materials used
|
ATEX Approval |
ATEX Approval
No
|
IECEx Approval |
IECEx Approval
No
|
Autoclavable |
Autoclavable
Yes
|
CIP |
CIP
Yes
|
Steam Sterilizable |
Steam Sterilizable
Yes
|
Operating Temperature Range |
Operating Temperature Range
Analog interface: 0 to 110 °C; Digital interface: 0 to 130 °C
|
Pressure Range bar g |
Pressure Range bar g
0 to 4 bar
|
Max. CO₂ Partial Pressure |
Max. CO₂ Partial Pressure
0.01 bar
|
Required Flow |
Required Flow
≥ 0.03 m/s
|
Automatic Polarization |
Automatic Polarization
Yes, max. 2 hours stabilisation time
|
