Arc Modbus Profinet Converter

Part # 10116586

The Arc Modbus Profinet Converter is a 24VDC DIN rail mounted device that can be used with up to four Arc sensors and converts their Modbus output to Profinet.

Receive More Information

Minimum: 1, Maximum: 1000

Arc Modbus Profinet Converter Details

This 24VDC DIN rail mounted Arc Modbus Profinet Converter facilitates the integration of up to four Arc sensors by converting their Modbus communication to the Profinet protocol.

Simplified integration of Hamilton Arc Sensors into your Profibus DP environment.

Reduce programming time and expenses associated with implementing different protocols.

Ensure compatibility of sensors and system by using Hamilton-developed Modbus Profibus Converter.

Multi-Sensor

Supports four Arc sensors and converts Modbus output to Profinet.

DIN Rail Mounted Design

Compact and easy-to-install for streamlined cabinet integration.

  • I could not be more pleased with my experience with Hamilton!

    My company has been using Hamilton probes for years and have always been happy with their performance! The team is always very helpful in trouble shooting issues and answering any questions that we may have about our probes. Overall, I could not be more pleased with my experience with Hamilton!

    Abigail Mann
    Bioprocessing Fermentation Associate at Heliae Development

Arc Modbus Profinet Converter Specifications

Print
Housing Material Polyamid
Measuring Channels 4
Dimensions (W x D x H) 23 x 115 x 111 mm
Sensor Compatibility pH, ORP, oDO, eDO, COND, UPW, DCO2, VCD, TCD Arc modbus sensors
Digital Interface Profinet
Operating Voltage 10 to 33 VDC
Operating Temperature Range -40 to 85 °C
Protection Rating IP20
