OneFerm pH LEVP 225 Pt1000

Part # 10184366

Hamilton OneFerm single-use pH sensors for biopharma offer reliable, stable measurements with easy integration into SU bioreactors and systems.

Receive More Information

Minimum: 1, Maximum: 1000

Commonly Grouped Accessories

OneFerm pH LEVP Details

The Hamilton OneFerm family of pH sensors represents a leading solution for single-use applications within the Pharmaceutical and Biotechnology Industries. These sensors are a significant advancement in single-use measurement, addressing common issues associated with traditional reusable pH sensors inserted into bags.

Combining the proven reliability and measurement stability of Hamilton's conventional sensors with the convenience of seamless integration into single-use bioreactors, OneFerm sensors offer high accuracy even after gamma irradiation and boast a sufficient shelf life. Their clog-free diaphragm ensures exceptionally low drift throughout the sensor's lifespan, and they can be customized to specific application requirements.

The OneFerm family is ideal for single-use bioreactors (both bag and rigid container types), single-use mixers, and single-use downstream processes.

Common applications Pharma & Biopharma, Bioprocess Downstream, Single-Use Bioprocessing, Bioprocess Upstream

Simplified integration of reliable, stable, and accurate pH measurement.

Featuring bio-compatibility, ready-to-use convenience, and a clog-free design.

Market-Leading Single-Use Solution

Recognized as a premier solution for a wide array of single-use applications within the Biopharmaceutical industry.

Ready to Use

Designed for immediate integration and use, simplifying setup and reducing preparation time.

Certified Bio-compatible

Materials used are certified bio-compatible, ensuring suitability for sensitive biopharmaceutical processes.

Clog-free Diaphragm

Clog-free diaphragm ensures extremely low drift during the service life of the sensor.

  • Hamilton pH sensors are characterized by their high measuring accuracy and long service life.

    Hamilton pH sensors are characterized by their high measuring accuracy and long service life. This contributes significantly to the control of our processes. They also help us to guarantee the required product quality and to further optimize processes.

    Felix Colin
    Bioprocess Engineer, AB Enzymes GmbH

OneFerm pH LEVP 225 Pt1000 Specifications

Print
Measurement Principle Combination electrode; pH potential measured against reference
Electrical Connector VP6
Measuring Range pH 3 to 10
Drift at Room Temperature < 0.1 pH per week after wet-in time, in buffer pH 7
Sensitivity Before gamma irradiation: 57 to 60 mV/pH at 25 °C (97 % -101 %); Shift after gamma irradiation: ± 1.5 mV/pH
Zero Point Before gamma irradiation: ± 20 mV; Shift after gamma irradiation: ± 10 mV
Calibration Data Yes, provided on sensor label
pH Accuracy After gamma irradiation and dry storage: ± 0.15 pH with provided calibration values.
± 0.1 pH after product calibration at the measurement temperature and within 2 pH units from the product calibration point
Membrane Shape Spherical
Diaphragm HP-Coatramic
Liquid Earth Yes
Temperature Sensor Pt1000
O-ring Material FDA 21 CFR 177.2600; EC 1935/2004; USP <87>; USP <88> Class VI (121 °C)
Biocompatibility Yes, tested according to ISO 10993-5 and USP <87>
Wet-in Time 30 min after dry storage
Shelf Life 12 months prior gamma irradiation. 18 months after gamma irradiation
Sensor Output Traditional: mV
Wetted Parts GΙass
VMQ (Silicone elastomer)
Process Connection PG13,5
Diameter 12 mm
Autoclavable No
Steam Sterilizable No
CIP No
Operating Temperature Range 4 to 50 °C
Sample min Conductivity 100 µS/cm
Pressure Range bar g 0 to 2 bar
a-length 225 mm
