OxyFerm FDA MS 160

Part # 10069701

The OxyFerm FDA Memosens is an electrochemical oxygen sensor specifically designed for hygienic applications with stringent requirements, such as those found in the pharmaceutical, biotechnology, and food and beverage industries.

Receive More Information

Minimum: 1, Maximum: 1000

Commonly Grouped Accessories

OxyFerm FDA MS Details

OxyFerm FDA Memosens is an electrochemical polarographic dissolved oxygen (DO) sensor specifically designed for applications with high demands for hygiene in the pharmaceutical, biotechnology, and food & beverage industries. Building on Hamilton's proven electrochemical DO sensor technology, OxyFerm FDA provides reliable dissolved oxygen measurements across a wide measuring range while meeting the requirements of hygienic production processes.

The sensor is equipped with a specially designed FDA-approved membrane with a rounded geometry that helps prevent gas bubble accumulation and ensures reliable measurement performance in sterile process environments. Its robust construction withstands steam sterilization, autoclaving, and CIP cleaning, supporting long-term operation under demanding hygienic process conditions.

The OxyFerm FDA Memosens offers increased installation flexibility through a wide range of electrical connectors, process mounting options, and optional accessories. The traditional nanoamp (nA) output enables compatibility with a broad range of commercially available transmitters and process control systems.

Combining hygienic design, robust construction, and reliable electrochemical measurement technology, OxyFerm FDA provides a dependable solution for dissolved oxygen monitoring in sterile and hygienic process applications.

Common applications Water, Energy, & Environment, Power Generation, Agri-Food and Beverage, Brewing, Winemaking

Upgrade existing systems with Memosens technology for digital signal transmission.

Resist harsh cleaning processes for long-lasting performance.

Memosens Digital Technology

Enables easy plug-and-play integration into existing systems.

Hygienic Compliance

FDA-approved membrane meets strict hygiene requirements.
Ideal for pharmaceutical, biotech, and food & beverage industries.

  • I could not be more pleased with my experience with Hamilton!

    My company has been using Hamilton probes for years and have always been happy with their performance! The team is always very helpful in trouble shooting issues and answering any questions that we may have about our probes. Overall, I could not be more pleased with my experience with Hamilton!

    Abigail Mann
    Bioprocessing Fermentation Associate at Heliae Development

  • We particularly appreciated the professional and personable approach.

    The training on pH sensors was highly beneficial for us. After a detailed introduction to the fundamentals of pH measurement, electrode measurement principles, and the topic of troubleshooting/prevention, we had sufficient time to ask our specific questions. This enabled us to apply what we learned immediately and integrate it directly into our laboratory routine. We particularly appreciated the professional and personable approach of Mrs. Näf-Rüdiger, who guided us through the informative and application-oriented training session.

    Romy Alisch
    Scientist, Novozymes Berlin GmbH, Germany

  • Hamilton pH sensors are characterized by their high measuring accuracy and long service life.

    Hamilton pH sensors are characterized by their high measuring accuracy and long service life. This contributes significantly to the control of our processes. They also help us to guarantee the required product quality and to further optimize processes.

    Felix Colin
    Bioprocess Engineer, AB Enzymes GmbH

OxyFerm FDA MS 160 Specifications

Print
Process Connection PG13,5
Sensor Family OxyFerm FDA MS
Wetted Parts Stainless Steel 1.4435
EPDM (Ethylene propylene elastomer)
FKM (Fluorocarbon Elastomer)
VMQ (Silicone elastomer)
See compliance details in Material Specification document
Electrical Connector Memosens
Measuring Range 10 ppb to 40 ppm (DO) or 0.2 to 1000 mbar (pO₂)
Electrolyte Oxylyte
Drift at Room Temperature < 1 % per week
Membrane Cap FDA
Oxygen Consumption Ca. 20 ng/h in air at 25 °C
Temperature Sensor NTC 22 kOhm
Current in Air at 25 °C 40 - 80 nA
Surface Quality of Steel Ra < 0.4 µm (N5)
Electrode system Silver platinum combination
Polarization Voltage and Time -670 ± 50 mV, ≥ 2 hours
Serial Number Yes
Response Time t98% < 60 s at 25 °C
Certificate Material and Performance Test Certificate
ATEX Approval II 1 G Ex ia IIC T3/T4/T6 Ga
IECEx Approval II 1 G Ex ia IIC T3/T4/T6 Ga
Diameter 12 mm
Autoclavable Yes
Steam Sterilizable Yes
CIP Yes
Operating Temperature Range 0 to 130 °C
Pressure Range bar g 0 to 4 bar
Max. CO₂ Partial Pressure 0.01 bar
Required Flow ≥ 0.03 m/s
a-length 160 mm

OxyFerm FDA MS 160 Resources

Browse app notes, user guides, specification documents, and more in our Knowledge Center.

Browse app notes, user guides, specification documents, and more in our Knowledge Center.

Browse app notes, user guides, specification documents, and more in our Knowledge Center.

Sensor Output signal diagram

Article

Sensor Output Signal

As polarographic sensors generate an electrical signal, this article explores the math used to determine the relationship between oxygen and current output.
Polarographic do sensor diagram

Article

What is a Polarographic Dissolved Oxygen Sensor?

This article discusses polarographic dissolved oxygen sensors. A polarographic sensor is commonly used to determine the dissolved oxygen concentration in a liquid.
Green circle icon with a dark navy lightbulb containing two interlocking gears, on a teal dotted background.

Article

Common Questions for Autoclave Sterilization of Sensors

This brief article examines common questions from end-users about best practices for autoclaving Hamilton sensors.

Browse app notes, user guides, specification documents, and more in our Knowledge Center.

Two overlapping green speech bubbles with a question mark on a dark navy circular background

FAQ

What is Memosens?

Memosens is a communication protocol for sensors. It allows digital communication with Memosens transmitters such as the Hamilton H220x transmitter.
Two overlapping green speech bubbles with a question mark on a dark navy circular background

FAQ

Does salinity impact my DO measurement?

Yes, salinity of a solution generally has an inverse relationship to the dissolved oxygen content within the solution. Arc sensors can have the salinity value of the liquid added in to correct the measurement by using ArcAir.
Two overlapping green speech bubbles with a question mark on a dark navy circular background

FAQ

How much torque is needed to install a sensor with PG13.5 threads?

Sensors with PG13.5 threads rely on the o-ring to seal against process pressure. Finger-tight (approximately 2 Newton Meter or 18 inch-lb) should be sufficient to install the sensor without leakage. Additional tightening beyond this can deform the o-ring or strip the threads.
