Microlab 600 Advanced Single Syringe Dispenser
Part # ML620-DIS
The Microlab 600 Advanced Single Syringe Dispenser leverages positive displacement pipetting and advanced touchscreen controls to easily and reliably dispense and aliquot in medium-throughput applications.
Commonly Grouped Replacement Parts
-
Microlab 600 Universal Valve - LeftReplacement Parts
-
Microlab 600 Concorde Convertible Tip Hand ProbeReplacement Parts
-
18 Gauge Fill Tubing, Blunt, PN: 61615-01Replacement Parts
-
18 Gauge Dispense Tubing, Tapered, PN: 240134Replacement Parts
-
12 Gauge Fill Tubing, Blunt, PN: 61614-01Replacement Parts
-
12 Gauge Dispense Tubing, Tapered, PN: 240133Replacement Parts
-
Accessory Holder with Tubing Management SystemReplacement Parts
-
Microlab 600 Base PlateReplacement Parts
Microlab 600 Advanced Single Syringe Dispenser Details
The Microlab ML620-DIS is a semi-automated liquid dispenser that combines positive displacement technology and a high-precision stepper motor to deliver volumes ranging from 500 nL to 50 mL with over 99% accuracy. Unlike traditional pipetting methods, its accuracy remains unaffected by a liquid’s viscosity, vapor pressure, or temperature, ensuring reliable results every time. The chemically resistant fluid path and the PTFE dispense tubing’s tapered tip further enhance usability.
Users can choose one from among many Bubble Free Prime syringes. These dispensing syringes offer multiple volume options and feature a conical plunger that reaches fully into the dispensing valve to minimize trapped air and reduce the need for frequent priming.
With its easy-to-navigate touchscreen interface and advanced control software, the ML620-DIS empowers users to create and store custom methods, transfer methods, manage all log files for regulatory compliance, and much more.
Includes:
(1) Single Syringe Pump
(1) Dispense Tubing Assembly
(1) Advanced Controller
(1) Valve Plug
(1) Concorde Hand Probe
(1) Cable Management System
(1) Valve (Left)
(1) Tubing Clip
(1) Fill Tubing Assembly
(1) Power Supply / Cord
(1) Syringe
(1) Base Plate (Not Pictured)
*Syringe volume must be selected
Common applications Analytical Chemistry, Dilutions and Dispensing, Liquid Chromatography-Mass Spectrometry
Outperform manual dispensing by completing more tasks in significantly less time
Increase dispensing process consistency and mitigate sources of error
Comply with quality and regulatory guidelines
Microlab 600 IQ / OQ / PQ
Instruction
Microlab 600 Series Syringes
- Bubble Free Prime syringes feature a conical plunger tip that enters the valve chamber, helping to purge air from the fluid path and reducing the number of required priming cycles.
- SaltLine syringes are designed to accommodate high salt containing fluids.
ML600 Dispensing Advantages
- Designed for reliability, the positive displacement method delivers precise volumes—even with volatile, dense, or high-viscosity liquids.
- Users can define dispense volumes with resolution finer than 0.01% of the syringe’s total capacity.
- The low-profile Concorde CT Hand Probe reduces hand fatigue during extended use. Enhance usability further with optional accessories such as the Luer lock conversion kit and foot switch.
Microlab Dispenser Advanced Control
- Features basic functionalities such as the Quick Start interface, real-time pump status, and adaptive dispense control.
- Enhance efficiency with method wizards (aliquot, serial dispense, titrate, pipette), a favorites menu, and a step-by-step configuration guide.
- Tailor dispensing operations to your application using custom method programming—store and execute up to 1,000 methods per controller.
