ZEUS X5 Automated Air Displacement Pipette, PN: 6606801-05

Part # 6606801-05

ZEUS X5 (Z-Excursion Universal Sampler™ - eXchange Series 5 mL) is an automated air displacement pipette designed for seamless OEM integration. Combining Hamilton’s revolutionary air displacement pipetting technology with our advanced CO-RE technology ensures process security from start to finish. ZEUS X5 is designed for accurate and precise liquid handling from 50 µL to 5 mL.

Receive More Information

Minimum: 1, Maximum: 0

ZEUS X5 Automated Air Displacement Pipette, PN: 6606801-05 Specifications

Print
Accuracy <1% at 5000 µL, <5% at 50 µL
Precision <0.5% at 5000 µL, <2.5% at 50 µL
Weight 1350 g
Power Requirements 36.9-50 VDC, 2 A
Communication Interface CAN (Hamilton protocol), FCC connector
Baud Rate 125,500 kBaud (others on request)
Operating Temp High 32 °C (90 °F)
Operating Temp Low 18 °C (64 °F)
Operating Humidity 15% to 85% (no condensation, indoors)
Storage Temp High 70 °C (158 °F)
Storage Temp Low -25 °C (-13 °F)
Storage Humidity 15% to 85% (no condensation, indoors)
z-Drive Excursion 200 mm
z-Drive Resolution 0.1 mm
z-Drive Maximum Speed 350 mm/sec
Volume Range 50 μL - 5000 μL
Pipetting Resolution 0.1 µL
Maximum Pipetting Speed 2,500 μL/s (peak speed)
Pipetting Mode Single and aliquot dispensing
Tip Detection Yes
Liquid Level Detection Pressure-based (pLLD) and capacitive detection (cLLD)
Pipetting Security Qualitative Pipette Monitoring (QPM) Anti-Droplet Control (ADC)
Operating Noise < 60 dBA, Indoor use only
Device Addressing up to 31 modules on a single CAN bus
Dimensions (D x H x W) 17 mm x 191 mm x 335 mm
RoHS Compliant Yes
Compatible CO-RE Tips 4000 μL tip, 5000 μL tip
