Hygienic Socket

The Hygienic Socket 1.4404 with its space saving design and simple sterilization is ideal to weld in fermenters or small pipes. Developed for easy installation and maintenance, the socket improves the cleaning process and increases safety.

Receive More Information

  • Hygienic socket illustration
  • Sensor hygienic socket

Hygienic Socket Details

The space-saving, easily sterilized Hygienic Socket is ideal for welding into fermenters or small pipes. Its benefits extend to water treatment, pharmaceutical, and chemical tanks/pipes.

Designed for 120mm sensors, it offers easy installation, maintenance, improved cleaning, and increased safety. Two "Life Guard" openings indicate seal failures. The Hamilton DO Adapter allows variable sensor insertion depth for dissolved oxygen or conductivity.

Common applications Pharma & Biopharma, Biotechnology, Water, Energy, & Environment, Agri-Food and Beverage, Novel Food Bioprocessing

Flexible housing positioning for optimal measurement performance.

Easy and time saving o-ring replacement.

Space saving design and simple sterilization.

Patented Sealing Design

  • Patented, hygienic, and safe sealing design.
  • Two “Life Guard” openings provide an indication of sealing failures.

Adjustable Insertion Depth

The sensor insertion depth can be adjusted for DO or Conductivity sensors by using the Hygienic Socket DO Adapter.

  • I could not be more pleased with my experience with Hamilton!

    My company has been using Hamilton probes for years and have always been happy with their performance! The team is always very helpful in trouble shooting issues and answering any questions that we may have about our probes. Overall, I could not be more pleased with my experience with Hamilton!

    Abigail Mann
    Bioprocessing Fermentation Associate at Heliae Development

Hygienic Socket Specifications

Print
Process Connection Welded
For Sensors with 120 mm, 12 mm, PG13,5
Sensor Insertion Depth 23.5 mm
Surface Quality of Steel Ra < 0.4 µm (N5, electropolished)
Housing Insertion Depth 0 to 55 mm
Max. Diameter 28 mm
Min. Total Length 107 mm
Weight 350 g
Serial Number Yes
Certificate Yes, 3.1 certificate with heat number
ATEX Approval II 1/2 G Ex ia IIC T4/T5/T6 Ga/Gb
II 1/2 D Ex ia IIIC T x °C Da/Db
IECEx Approval II 1/2 G Ex ia IIC T4/T5/T6 Ga/Gb
II 1/2 D Ex ia IIIC T x °C Da/Db
EAC Ex Approval II 1/2 G Ex ia IIC T4/T5/T6 Ga/Gb
II 1/2 D Ex ia IIIC T x °C Da/Db
UKEx Approval II 1/2 G Ex ia IIC T4/T5/T6 Ga/Gb
II 1/2 D Ex ia IIIC T x °C Da/Db
Diameter 28 mm
Autoclavable Yes
Steam Sterilizable Yes
CIP Yes
Operating Temperature Range -10 to 140 °C
Max. Pressure bar g 16 bar
Product Family Hygienic Socket
Wetted Part EPDM (Ethylene propylene elastomer), EPDM (FDA approved, USP Class VI), see compliance details in Material Specification document

Hygienic Socket Resources

Browse app notes, user guides, specification documents, and more in our Knowledge Center.

Browse app notes, user guides, specification documents, and more in our Knowledge Center.

Browse app notes, user guides, specification documents, and more in our Knowledge Center.

Article

Hygienic Socket Overview

The Hamilton Hygienic Socket is a unique sensor holder that directly replaces the traditional G1-1/4" 25mm Ingold socket and FlexiFit sensor holder with a single insertion device. This short article looks more closely at the design and function of this product.

Article

What type of process connection does my sensor have?

There are multiple styles of process connections found on sensors. View each connection to help understand what may fit your needs.

Browse app notes, user guides, specification documents, and more in our Knowledge Center.

FAQ

What is the Hygienic Socket?

The Hygienic Socket is a single product that combines the functionality of a welded socket along with a static sensor housing all in one device. The Hygienic Socket welded directly into the side of the vessel. Any 120mm by 12mm diameter sensor can be directly inserted to make a sanitary installation. The Hygienic socket reduces the cost and complexity of installing sensors into stainless steel vessels.
