FlushTrode

Part # 238060

The FlushTrode pH sensor has an adjustable sleeve diaphragm that supports measuring pH in strongly contaminated or proteinaceous solutions, non-aqueous media, and other laboratory areas unsupported by traditional pH probes.

Buy Now

Price

$

Minimum: 1, Maximum: 1000

FlushTrode Details

Engineered for accurate pH measurement in viscous, high-solid media, contaminated solutions, and non-aqueous media, the FlushTrode pH sensor features a standard combination sensor with a ground sleeve liquid junction. The specialized design of this glass pH probe prevents clogging from solids, proteins, and fats while minimizing contamination risk. FlushTrode pH sensors resist chemical and mechanical damage for reduced maintenance needs and extended probe service life. Additionally, this pH probe offers fast and reliable drift-free pH measurements in any laboratory environment. The FlushTrode pH sensor has limited use in process control applications where vibration is present.

Common applications Chemical Processes, Agri-Food and Beverage

Clog-resistance in any challenging aqueous solutions or non-aqueous media.

Save maintenance time and extend the service life of the pH sensor via self-cleaning functionality.

Rapidly, and accurately performs in areas where traditional pH sensors struggle.

Rugged Sleeve Diaphragm Design

  • Prevents clogging from solids, proteins, and fats.
  • Ideal for viscous, high-solid, and sticky samples, including those in cosmetics, food & beverage, and biopharma applications.

Long Sensor Lifespan

  • High resistance to chemicals and mechanical interference as well as temperature and pressure fluctuations.
  • Simple cleaning reduces the need for frequent sensor replacements.
  • Delivers stable, drift-free pH measurements over time.

  • Hamilton pH sensors are characterized by their high measuring accuracy and long service life.

    Hamilton pH sensors are characterized by their high measuring accuracy and long service life. This contributes significantly to the control of our processes. They also help us to guarantee the required product quality and to further optimize processes.

    Felix Colin
    Bioprocess Engineer, AB Enzymes GmbH

  • The measurement technology from Hamilton is hard to beat in terms of its measurement accuracy and reliability.

    The measurement technology from Hamilton that is used in our brewery is hard to beat in terms of its measurement accuracy and reliability. The planning security and cost stability with the subscription is very attractive and important to us. Hamilton offers great support and is always open to customer requests.

    Holger Bruckes
    Deputy head of Quality Assurance Mönchengladbach Brewery, Branch of OETTINGER Brewery GmbH

  • I could not be more pleased with my experience with Hamilton!

    My company has been using Hamilton probes for years and have always been happy with their performance! The team is always very helpful in trouble shooting issues and answering any questions that we may have about our probes. Overall, I could not be more pleased with my experience with Hamilton!

    Abigail Mann
    Bioprocessing Fermentation Associate at Heliae Development

FlushTrode Specifications

Print
Sensor Family FlushTrode
Wetted Parts GΙass
FEP (Fluorinated Ethylene Propylene)
pH Glass Hamilton Type HF Glass
Electrical Connector S7
a-length 120 mm
Parameter pH
Measuring Range pH 0 to 14
Electrolyte 3 M KCl
Sensitivity 57 to 59 mV / pH at 25 °C
Zero Point 0 ± 20 mV
pH Glass Resistance Moderate
Membrane Shape Spherical
Diaphragm Sleeve
Number of Diaphragms 1
Reference System Hamilton Everef
Temperature Sensor No
Serial Number Yes
Recommended Storage Hamilton Storage Solution or 3 M KCl
Certificate Yes, with measured values in Buffer pH 4.01 and pH 7.00
Diameter 12 mm
Operating Temperature Range -10 to 80 °C
Pressure Range bar g Atmospheric pressure
