5 mL Gastight Syringe Model 1005 SL, Gastight Syringe, Sample Lock (SL), PN: 81556

22 gauge, 2 inch (51 mm), Point Style 2: Curved, Beveled

Part # 81556

This 1000 series syringe is a 5 mL Gastight #1005 syringe designed to manually dispense heterogeneous, volatile, and viscous samples. Commonly used with instruments, this syringe (PN: 81556) has a Sample Lock (SL) termination.

Buy Now

Price

$

Minimum: 1, Maximum: 1000

5 mL Gastight Syringe Model 1005 SL, Gastight Syringe, Sample Lock (SL), PN: 81556 Details

Hamilton's 1000 series, Gastight #1005 Sample Lock (SL) Syringes are designed for convenient sample collection and transport.  Its unique twist valve mechanism simplifies operation.  These syringes are suitable for dispensing both liquids and gases, utilizing a polymer plunger tip to ensure a leak-free seal.  The gastight series offers a broad spectrum of volume capacities, terminations, needle options, and plunger styles, providing exceptional versatility for various applications.  Manufactured with high-quality, chemically resistant materials, Hamilton syringes are known for their ± 1% accuracy and robust durability.

Compatible with Large RN Hub Needles

Polymer Plunger Tip

  • A white polymer plunger tip effectively wipes the glass barrel, creating a leak-free seal.
  • Ensures a Gastight performance, suitable for liquids and gases.

SampleLock Twist Valve

  • Equipped with a unique, easy-to-use ON/OFF valve for seamless sample collection, transport, storage, and analysis.
  • Perfect for handling liquid and gaseous samples that are volatile or susceptible to environmental contamination.

Scientific Citations

  • Hamilton Gastight SampleLock Syringes for Precision GC Sampling And Analysis

    Hamilton gas-tight syringes are invaluable in this process to avoid gas loss between culture sampling and GC injection. Additionally, many of our cultures produce methane in relatively low abundances, making it more critical to avoid sample loss. For such cases, we use Hamilton gas-tight syringes with sample locks to prevent such losses and ensure accurate GC measurements.

    Beverly Chiu
    Research Staff, Dartmouth College | Earth Science

5 mL Gastight Syringe Model 1005 SL, Gastight Syringe, Sample Lock (SL), PN: 81556 Specifications

Print
Volume 5 mL
Syringe Type Gastight
Syringe Series 1000
Termination Sample Lock (SL)
Needle Large RN
Gauge 22 gauge
Point Style 2: Curved, Beveled
Needle Length 2 inch (51 mm)
Plunger Style Standard Plunger
Fluid Path SST, Borosilicate glass, PTFE
Autoclavable No
Gas Sterilizable Yes
Pressure 200 psig (13.8 bar)
Maximum Operating Temperature 80°C / 176°F
Minimum Operating Temperature 10°C / 50°F
Barrel Inner Diameter 0.406 inches (10.3 mm)
Barrel Outer Diameter 0.530 inches (13.5 mm)
Needle Inner Diameter 0.0161 inches (0.41 mm)
Needle Outer Diameter 0.0283 inches (0.72 mm)
Std Needle Dead Volume 6.81 µL
Sales Quantity 1 syringe per pack
Syringe Model Number 1005

5 mL Gastight Syringe Model 1005 SL, Gastight Syringe, Sample Lock (SL), PN: 81556 Resources

Browse app notes, user guides, specification documents, and more in our Knowledge Center.

Browse app notes, user guides, specification documents, and more in our Knowledge Center.

Browse app notes, user guides, specification documents, and more in our Knowledge Center.

Syringes Graduations

Article

Syringe Graduations

Another aspect of proper syringe selection requires knowing the graduations visible on a particular syringe series and volume. This detailed table of data provides scale length, total scale divisions, major graduations, minor graduations, and sub-minor graduations of each syringe series by volume.
Hamilton 59000-15, 50 Microliter Gastight Model 1705 Bubble Free Prime Instrument Syringe

Article

Gastight Syringe Operating Parameters

Access operating parameters for Hamilton’s Gastight Syringes, including the 1000, 1700, and 1800 Series, as well as Super Syringes. Ensure optimal performance and compatibility for your application.
Syringe Cleaning Kit

Article

Syringe Sterilization and Disinfecting Guide

Are you curious whether your Hamilton syringe can be sterilized and disinfected via ethylene oxide, autoclavation, or chemical disinfectants? Consult this table of syringe terminations, syringe needles, and tubing types to learn the possible ways to sterilize and disinfect your Hamilton syringe.

Browse app notes, user guides, specification documents, and more in our Knowledge Center.

Accuracy of Hamilton syringes 1

FAQ

What are the most versatile syringes made by Hamilton?

Gastight syringes are the most versatile syringes. Plungers are replaceable if they get bent. Any of the Metal hub, Kel-F or Removable needle allow for the replacement of needle if they become bent or plugged.
Plunger faq

FAQ

Can I order a replacement plunger for my syringe?

Most Gastight syringes have replacement plungers available under 'Accessories' on the product page, while Microliter syringes do not. 7000 series modified Microliter syringes have zero dead volume and a small plunger wire, but it's best not to remove the needle or plunger to avoid damaging the wire.
Accuracy of Hamilton syringes 1

FAQ

How can I sterilize my syringe?

Chemical sterilization is the preferred method for all Hamilton products. Autoclaving syringes should only be used as a last resort and only where specifically stated. Syringe sterilization is not straightforward. Not all syringes can be autoclaved.
