1.25 mL, Gastight Syringe, Bubble Free Prime (BFP, 5/16"-28), PN: 69005-40

No Needle Available

Part # 69005-40

This 1000 series syringe is a Gastight 1.25 mL syringe designed to manually dispense heterogeneous, volatile, and viscous samples. Commonly used with instruments, this syringe (PN: 69005-40) has a Bubble Free Prime™ (BFP, 5/16"-28) termination.

Receive More Information

Minimum: 1, Maximum: 1000

1.25 mL, Gastight Syringe, Bubble Free Prime (BFP, 5/16"-28), PN: 69005-40 Details

Hamilton's  1000 series, Gastight, Half-Height, Long-Life #1002 Bubble Free Prime (BFP, 5/16"-28) Syringes with X-Style plunger features a conical plunger tip which extends through the threaded termination of the syringe and into the valve. This unique design expels the air from the syringe and valve decreasing the number of cycles required to prime the fluid path.

This series of syringes is ideal for dispensing both liquids and gases.  Long-Life Half-Height Syringes are designed for durability and precision. Featuring a plunger tip made from Ultra High Molecular Weight Polyethylene (UHMWPE), this syringe offers superior resistance to abrasion. It is specifically developed to withstand extreme and harsh conditions. With a 30 mm stroke length, it is compatible with Hamilton's PSD/ 4 Syringe Pumps, making it ideal for applications requiring precise liquid handling and robust performance in demanding environments.


Longlife Polymeric Plunger Tip

  • Crafted from Ultra High Molecular Weight Polyethylene (UHMWPE) for exceptional abrasion resistance.
  • Engineered to endure extreme and harsh conditions.

Bubble Free Prime Plunger Tip

  • Features a conical plunger tip that extends through the 5/16" -28 threaded termination and into the valve.
  • This unique zero dead volume design expels air from the system and reduces the priming cycles required to eliminate air bubbles.

Scientific Citations

  • Gastight Syringes Ensures Integrity of Environment Sensitive Catalysts (or Samples)

    For such, we utilize highly reactive catalysts that are in many cases air and moisture-sensitive. Gastight Hamilton syringes are essential to maintaining the catalyst integrity and, therefore, ensuring reproducible and trustable results.

    Stella A. Gonsales
    Assistant Professor, University of Chemistry and Technology Prague | Department of Polymers

1.25 mL, Gastight Syringe, Bubble Free Prime (BFP, 5/16"-28), PN: 69005-40 Specifications

Print
Volume 1.25 mL
Syringe Type Gastight, Bubble Free Prime, Half-Height, Long-Life
Syringe Series 1000
Termination Bubble Free Prime™ (BFP, 5/16"-28)
Needle No Needle Available
Plunger Style X-Style
Fluid Path Borosilicate glass, UHMWPE, PFA
Autoclavable No
Gas Sterilizable Yes
Pressure 200 psig (13.8 bar)
Maximum Operating Temperature 80°C / 176°F
Minimum Operating Temperature 10°C / 50°F
Barrel Inner Diameter 0.287 inches (7.29 mm)
Barrel Outer Diameter 0.407 inches (10.3 mm)
Sales Quantity 1 syringe per pack
Plunger Tip Material UHMWPE

1.25 mL, Gastight Syringe, Bubble Free Prime (BFP, 5/16"-28), PN: 69005-40 Resources

Browse app notes, user guides, specification documents, and more in our Knowledge Center.

Browse app notes, user guides, specification documents, and more in our Knowledge Center.

HAM Reference Guide Syringes Needles

Catalog

Reference Guide - Laboratory Syringes and Needles

The Syringe and Needle Reference Guide provides detailed information on Hamilton’s full portfolio of syringes and needles. Everything from cleaning to selection charts to help you choose between syringe terminations.
HAM Guide Syringe Use Care

Guide

Syringe Care and Use Guide

Hamilton’s Syringe Care and Use guide outlines the basics of daily syringe use and operation so that scientists and technicians can achieve the highest level of accuracy and precision. Important topics covered include inspection, operating temperature, trapped air, and sample carryover.
HAM Catalog Selecting Right Syringe

Guide

Hamilton Guide to Selecting the Right Syringe

Select the right type of syringe for your manual application. View our syringe size chart and learn more about Hamilton's lab syringe needles in this guide. Top-quality materials and skilled workmanship ensure that our syringes consistently deliver the highest performance for reliable analyses.

Browse app notes, user guides, specification documents, and more in our Knowledge Center.

Accuracy of Hamilton syringes 1

FAQ

What is the difference between Bubble Free Prime (BFP) Syringes and Luer Lock (TLL) Syringes?

For any syringe pump, the key to achieving the most accurate dispenses is eliminating all air from the fluid path. Traditional syringes trap approximately 50 μL of air between the tip of the syringe and the valve. For small syringes, this trapped air is the last to leave the syringe and the first to be drawn back in, making them difficult to prime. The Bubble Free Prime (BFP) syringe features a conical plunger tip which expels the air from the syringe and valve decreasing the number of priming cycles required to eliminate air bubbles from within the flow path.
