Sensors for Single-Use
Our trusted sensor technology for single-use environments.
Our Single-Use Product Portfolio
Single-Use Sensor Elements
Reusable Sensor Parts
Arc Modules
Designed specifically to meet your single-use requirements.
Our single-use sensors combine the reliability and measurement stability of our long-term proven conventional sensors with the ease of use as an integral part of the bioreactor. The sensors retain high accuracy performance even after gamma irradiation and offer a sufficient shelf life, making them the ideal single-use solution.
Hamilton Single-Use Sensor Benefits
Learn More About Single-Use Sensors
/
Specifications
| Criteria | Description |
|---|---|
| Gamma Sterilization | 50 kGy |
| Dry Storage Time | Before irradiation: 12 months for all sensors After irradiation: 18 months pH, 24 months all other sensors |
| Pressure Range | 0 to 1 bar |
| Wet-in Time | < 30 minutes prior to measurement |
| Cytotoxicity | ISO 10933-5 and USP <87> |
One Vendor, All the Measurements
Hamilton has worked closely with single-use bag manufacturers to understand the market needs.
Wide Variety of Measurements
Whether media prep, mixing, or cell culture, each application has different sensing requirements. Hamilton’s reusable measurement technologies
have been adapted for single-use bag installations.
Designed for Your Needs
There are no accordion-style insertion devices or probe assemblies that must be autoclaved. Single-use sensors come with either weld-in style measurement elements or work with industry standard port fittings. All products can be gamma sterilized with the bag prior to use.
Solutions for Single-Use Bioreactors
Technology You Can Trust
Reliable glass membrane pH technology offers a proven measurement with broad range and very low drift after wet-in. The OneFerm is available in lengths from 70 to 425 mm so that your entire bioreactor product family can be outfitted with single-use specific pH sensors.
The unique S2 optical DO cap mounts on an insertion tube from the bioreactor headplate. It uses the same technology as the industry leading VisiFerm Optical DO sensor.
General Requirements for All Sensors
- 3rd party test data available for review
- Packaging suitable for clean room environments
- All sensor elements are pre-calibrated for manual input; No shift due to gamma irradiation
How Do I Purchase Single-Use Sensors?
Hamilton single-use sensors are currently only available to integrators such as bag, bioreactor, and downstream skid manufacturers.
- Bioreactor, bag, and downstream skid manufacturers are encouraged to contact Hamilton to discuss integration opportunities.
- End-users at biopharmaceutical companies are encouraged to ask their single-use solution provider if Hamilton sensors are available for their installation.
Sensors for Single-Use Resources
Browse app notes, user guides, specification documents, and more in our Knowledge Center.
Browse app notes, user guides, specification documents, and more in our Knowledge Center.
Browse app notes, user guides, specification documents, and more in our Knowledge Center.
Browse app notes, user guides, specification documents, and more in our Knowledge Center.
Backed by world-class service and support.
For over 75 years, the Hamilton name has been recognized globally for its unwavering commitment to quality. That pledge extends to creating long-term customer partnerships. We're proud to offer in-depth training courses, on-site field support, custom product builds, and so much more.
Let's Talk
Connect with a Hamilton expert to discuss solutions for your workflow. We are here to enable your success.
