Specifications
Weight |
Weight
410 g
|
---|---|
Power Requirements |
Power Requirements
24 VDC ±5%, 200 mA
|
Communication Interface |
Communication Interface
RS-232 or CAN (Hamilton Protocol)
|
Baud Rate |
Baud Rate
19,200 or 38,400 bd
|
Operating Temp High |
Operating Temp High
32 °C (90 °F)
|
Operating Temp Low |
Operating Temp Low
18 °C (64 °F)
|
Operating Humidity |
Operating Humidity
40% to 80%, non-condensing
|
Additional specifications
Storage Temp High |
Storage Temp High
70 °C (158 °F)
|
---|---|
Storage Temp Low |
Storage Temp Low
-25 °C (-13 °F)
|
Storage Humidity |
Storage Humidity
40% to 80%, non-condensing
|
Volume Range |
Volume Range
1 - 1,000 µL
|
Pipetting Resolution |
Pipetting Resolution
0.1 µL
|
Maximum Pipetting Speed |
Maximum Pipetting Speed
90 mm/s corresponding to 1,500 µL/s
|
Pipetting Mode |
Pipetting Mode
Single and aliquot dispensing
|
Tip Detection |
Tip Detection
Yes
|
Liquid Level Detection |
Liquid Level Detection
Pressure-based (pLLD) and capacitive detection (cLLD)
|
Pipetting Security |
Pipetting Security
Qualitative Pipette Monitoring (QPM) Anti-Droplet Control (ADC)
|
Operating Noise |
Operating Noise
< 60 dBA, Indoor use only
|
Device Addressing |
Device Addressing
up to 31 modules on a single CAN bus or 32 with RS-232
|
RoHS 3 Compliant |
RoHS 3 Compliant
Yes
|
